Description
The Integrated CNC Stone Engraving Machine is a high-precision CNC router designed for engraving, carving, relief machining, lettering, and detailed stone processing. Suitable for marble, granite, bluestone, quartz, jade, and engineered stone, it delivers exceptional accuracy, stability, and long-term reliability for professional fabrication workshops.
Its heavy-duty construction, high-speed spindle, and advanced CNC control system make it ideal for architectural stonework, monuments, decorative panels, and custom engraving applications.
Features
- High-Precision CNC Engraving
- Heavy-Duty Steel Frame Construction
- Water-Cooled High-Speed Spindle
- Linear Guide Rail Motion System
- High Accuracy & Repeatability
- G-Code & HPGL Compatible
- Automatic CNC Control System
- Continuous Machining After Power Recovery
- Compatible with Major CAM Software
- Suitable for Industrial Production
Applications
- Marble Engraving
- Granite Carving
- Monument Production
- Decorative Stone Panels
- Architectural Stone
- Custom Stone Artwork
- Jade & Crystal Processing
- Aluminum & Copper Plate Engraving
Technical Data
| Specification | SYNC-1325-1D | SYNC-3015-2D |
|---|---|---|
| Working Area (mm) | 1300 × 2500 | 3000 × 1500 |
| Feed Height (mm) | 450 | 450 |
| Air Speed (m/min) | 20 | 20 |
| Processing Speed (m/min) | 20 | 20 |
| Spindle Power | 7.5 kW Water-Cooled | 7.5 kW Water-Cooled |
| Spindle Speed (rpm) | 6000–24000 | 6000–24000 |
| Motor | Standard 1108 (Optional AC Digital Motor) | Standard 1108 (Optional AC Digital Motor) |
| Operating Voltage | AC220V/50Hz or AC380V/50Hz | AC220V/50Hz or AC380V/50Hz |
| Tool Diameter (mm) | Ø6 / Ø8 / Ø10 / Ø12 / Ø14 / Ø16 | Ø6 / Ø8 / Ø10 / Ø12 / Ø14 / Ø16 |
| File Format | G-Code / HPGL | G-Code / HPGL |
| Positioning Accuracy | ±0.02 mm | ±0.02 mm |
| Repeatability | ±0.01 mm | ±0.01 mm |
| Control System | Weihong / Mountain Dragon | Weihong / Mountain Dragon |
| Machine Dimensions (mm) | 3500 × 2200 × 2200 | 2200 × 4200 × 2200 |
| Machine Weight | 2600 kg | 3000 kg |
Compatible Materials
- Marble
- Granite
- Bluestone
- Engineered Stone
- Quartz
- Jade
- Crystal
- Agate
- Copper Plates
- Aluminum Plates
