Description:
The AT16 Autonomous Intelligent Grinder represents the pinnacle of large-scale floor grinding technology.
Specifications:
| Specification | Value |
|---|---|
| Product | AT16 Autonomous Floor Grinder |
| Motor Power | 22 kW / 30 HP × 2 |
| Rated Voltage | 380V, 3 Phase |
| Rated Current | 90 A |
| Frequency | 50/60 Hz |
| Inverter Power | — |
| Working Width | 1560 mm (61.4 in) |
| Grinding Discs | Ø315 mm (12.4 in) × 4 |
| Minimum Grinding Disc Speed | 350 rpm |
| Maximum Grinding Disc Speed | 1950 rpm |
| Minimum Ground Clearance | 112 mm (4.4 in) |
| Product Length | 3073 mm (121 in) |
| Product Width | 1628 mm (64.1 in) |
| Product Height | 2396 mm (94.3 in) |
| Machine Weight | Gearbox: 850 kgFrame: 1926.5 kgTotal Weight: 2776.5 kg |
